Mapping Availability Group Topology with AI
If you manage more than a couple of Availability Groups, you’ve probably experienced the moment where someone asks “which replicas are synchronous on AG3?” and you have to connect to the primary, open the dashboard, and click around. Or worse, someone changes a replica from asynchronous to synchronous commit “for testing” and forgets to change it back.
I wanted two things: a diagnostic query that shows the complete AG topology in one result set, and a way to detect misconfigurations automatically. The AI agent built both — and the iterative process of refining the output is a good example of how these conversations work in practice.
The First Prompt
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 |
Write a T-SQL diagnostic query that maps the complete Availability Group topology on the current instance. Show: 1. AG name and cluster type 2. Each replica: server name, role (PRIMARY/SECONDARY), availability mode (SYNCHRONOUS_COMMIT/ASYNCHRONOUS_COMMIT), failover mode, seeding mode 3. Synchronization health and connected state for each replica 4. Endpoint URL for each replica 5. Listener name, IP address, and port for each AG 6. Read-only routing URL and read-only routing list for each replica 7. Log send queue size and redo queue size per database per replica Use sys.availability_groups, sys.availability_replicas, sys.dm_hadr_availability_replica_states, sys.dm_hadr_database_replica_states, sys.availability_group_listeners, sys.availability_group_listener_ip_addresses, and sys.availability_read_only_routing_lists. Run from the primary replica. Format as multiple result sets if needed for readability. |
What the Agent Produced
The agent generated three separate queries — a smart choice, because cramming all this into one result set would be unreadable:
- Replica overview: AG name, replica server name, role, availability mode, failover mode, seeding mode, synchronization health, connected state, endpoint URL.
- Database-level detail: AG name, database name, replica server name, synchronization state, log send queue size (KB), redo queue size (KB), last commit time.
- Listener and routing: AG name, listener DNS name, IP address, port, read-only routing URL per replica, read-only routing list.
The join structure was correct — sys.availability_replicas joined to sys.dm_hadr_availability_replica_states on replica_id, with the database-level DMV joined on both replica_id and group_database_id. The agent correctly used LEFT JOIN for the listener queries since not every AG has a listener configured (distributed AGs, for example).
The Iteration: Misconfiguration Detection
The raw topology data is useful, but I wanted the script to actively flag problems. Here’s the follow-up prompt:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 |
Add a misconfiguration detection section that flags: 1. Async replicas configured with automatic failover (automatic failover requires synchronous commit) 2. Replicas with no read-only routing URL configured (means read-intent connections won't route to secondaries) 3. Synchronous commit replicas not in SYNCHRONIZED state (indicates a problem — latency, network issues, or suspended data movement) 4. Replicas in a DISCONNECTED state 5. Databases with redo queue > 500 MB (secondary falling behind) 6. Databases with log send queue > 500 MB (network or throughput issue) 7. Any replica with seeding_mode = MANUAL where the database is not yet joined Label each finding with a severity: CRITICAL, WARNING, or INFO. |
The agent produced a UNION ALL query that checked each condition and returned a uniform result set: [Severity], [Category], [AGName], [ReplicaServer], [DatabaseName], [Finding]. Clean and actionable.
I refined one thing: the redo and log send queue thresholds. 500 MB is a reasonable starting point, but in environments with high transaction volumes or large databases, a sustained queue of 200 MB might already indicate a problem. I parameterized the thresholds:
|
1 2 |
DECLARE @RedoQueueThresholdKB bigint = 512000; /* 500 MB */ DECLARE @SendQueueThresholdKB bigint = 512000; /* 500 MB */ |
The Final Script
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 |
/* AG Topology Diagnostic — run from primary replica */ SET NOCOUNT ON; DECLARE @RedoQueueThresholdKB bigint = 512000; DECLARE @SendQueueThresholdKB bigint = 512000; /* Result Set 1: Replica Overview */ SELECT ag.[name] AS [AGName] ,ar.[replica_server_name] AS [ReplicaServer] ,ars.[role_desc] AS [CurrentRole] ,ar.[availability_mode_desc] AS [AvailabilityMode] ,ar.[failover_mode_desc] AS [FailoverMode] ,ar.[seeding_mode_desc] AS [SeedingMode] ,ars.[synchronization_health_desc] AS [SyncHealth] ,ars.[connected_state_desc] AS [ConnectedState] ,ar.[endpoint_url] AS [EndpointURL] FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] LEFT JOIN sys.[dm_hadr_availability_replica_states] AS ars ON ar.[replica_id] = ars.[replica_id] ORDER BY ag.[name], ars.[role_desc] DESC, ar.[replica_server_name]; /* Result Set 2: Database-Level Synchronization */ SELECT ag.[name] AS [AGName] ,adc.[database_name] AS [DatabaseName] ,ar.[replica_server_name] AS [ReplicaServer] ,drs.[synchronization_state_desc] AS [SyncState] ,drs.[synchronization_health_desc] AS [SyncHealth] ,drs.[log_send_queue_size] AS [LogSendQueueKB] ,drs.[redo_queue_size] AS [RedoQueueKB] ,drs.[last_commit_time] AS [LastCommitTime] ,DATEDIFF(SECOND, drs.[last_commit_time], GETDATE()) AS [CommitLagSeconds] ,drs.[is_suspended] AS [IsSuspended] ,drs.[suspend_reason_desc] AS [SuspendReason] FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] INNER JOIN sys.[dm_hadr_database_replica_states] AS drs ON ar.[replica_id] = drs.[replica_id] INNER JOIN sys.[availability_databases_cluster] AS adc ON drs.[group_database_id] = adc.[group_database_id] ORDER BY ag.[name], adc.[database_name], ar.[replica_server_name]; /* Result Set 3: Listeners and Read-Only Routing */ SELECT ag.[name] AS [AGName] ,agl.[dns_name] AS [ListenerName] ,lip.[ip_address] AS [ListenerIP] ,agl.[port] AS [ListenerPort] ,ar.[replica_server_name] AS [ReplicaServer] ,ar.[read_only_routing_url] AS [ReadOnlyRoutingURL] FROM sys.[availability_groups] AS ag LEFT JOIN sys.[availability_group_listeners] AS agl ON ag.[group_id] = agl.[group_id] LEFT JOIN sys.[availability_group_listener_ip_addresses] AS lip ON agl.[listener_id] = lip.[listener_id] INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] ORDER BY ag.[name], ar.[replica_server_name]; /* Result Set 4: Misconfiguration Detection */ SELECT [Severity], [Category], [AGName], [ReplicaServer], [DatabaseName], [Finding] FROM ( /* Async replica with automatic failover */ SELECT N'CRITICAL' AS [Severity] ,N'Invalid Config' AS [Category] ,ag.[name] AS [AGName] ,ar.[replica_server_name] AS [ReplicaServer] ,NULL AS [DatabaseName] ,N'Asynchronous replica configured for automatic failover — ' + N'automatic failover requires synchronous commit' AS [Finding] FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] WHERE ar.[availability_mode] = 0 /* ASYNCHRONOUS_COMMIT */ AND ar.[failover_mode] = 1 /* AUTOMATIC */ UNION ALL /* Missing read-only routing URL */ SELECT N'WARNING' AS [Severity] ,N'Routing' AS [Category] ,ag.[name] ,ar.[replica_server_name] ,NULL ,N'No read-only routing URL configured — read-intent ' + N'connections will not route to this secondary' FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] LEFT JOIN sys.[dm_hadr_availability_replica_states] AS ars ON ar.[replica_id] = ars.[replica_id] WHERE (ar.[read_only_routing_url] IS NULL OR ar.[read_only_routing_url] = N'') AND ars.[role] = 2 /* SECONDARY */ UNION ALL /* Synchronous replica not in SYNCHRONIZED state */ SELECT N'CRITICAL' AS [Severity] ,N'Sync Health' AS [Category] ,ag.[name] ,ar.[replica_server_name] ,NULL ,N'Synchronous commit replica is ' + ars.[synchronization_health_desc] + N' — expected HEALTHY' FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] INNER JOIN sys.[dm_hadr_availability_replica_states] AS ars ON ar.[replica_id] = ars.[replica_id] WHERE ar.[availability_mode] = 1 /* SYNCHRONOUS_COMMIT */ AND ars.[synchronization_health] <> 2 /* NOT HEALTHY */ AND ars.[role] = 2 /* SECONDARY */ UNION ALL /* Disconnected replica */ SELECT N'CRITICAL' AS [Severity] ,N'Connectivity' AS [Category] ,ag.[name] ,ar.[replica_server_name] ,NULL ,N'Replica is DISCONNECTED' FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] INNER JOIN sys.[dm_hadr_availability_replica_states] AS ars ON ar.[replica_id] = ars.[replica_id] WHERE ars.[connected_state] = 0 /* DISCONNECTED */ UNION ALL /* Large redo queue */ SELECT N'WARNING' AS [Severity] ,N'Redo Lag' AS [Category] ,ag.[name] ,ar.[replica_server_name] ,adc.[database_name] ,N'Redo queue is ' + CONVERT(nvarchar(20), drs.[redo_queue_size] / 1024) + N' MB — secondary is falling behind' FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] INNER JOIN sys.[dm_hadr_database_replica_states] AS drs ON ar.[replica_id] = drs.[replica_id] INNER JOIN sys.[availability_databases_cluster] AS adc ON drs.[group_database_id] = adc.[group_database_id] WHERE drs.[redo_queue_size] > @RedoQueueThresholdKB UNION ALL /* Large log send queue */ SELECT N'WARNING' AS [Severity] ,N'Send Lag' AS [Category] ,ag.[name] ,ar.[replica_server_name] ,adc.[database_name] ,N'Log send queue is ' + CONVERT(nvarchar(20), drs.[log_send_queue_size] / 1024) + N' MB — check network throughput' FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] INNER JOIN sys.[dm_hadr_database_replica_states] AS drs ON ar.[replica_id] = drs.[replica_id] INNER JOIN sys.[availability_databases_cluster] AS adc ON drs.[group_database_id] = adc.[group_database_id] WHERE drs.[log_send_queue_size] > @SendQueueThresholdKB UNION ALL /* Suspended data movement */ SELECT N'CRITICAL' AS [Severity] ,N'Data Movement' AS [Category] ,ag.[name] ,ar.[replica_server_name] ,adc.[database_name] ,N'Data movement suspended — ' + ISNULL(drs.[suspend_reason_desc], N'reason unknown') FROM sys.[availability_groups] AS ag INNER JOIN sys.[availability_replicas] AS ar ON ag.[group_id] = ar.[group_id] INNER JOIN sys.[dm_hadr_database_replica_states] AS drs ON ar.[replica_id] = drs.[replica_id] INNER JOIN sys.[availability_databases_cluster] AS adc ON drs.[group_database_id] = adc.[group_database_id] WHERE drs.[is_suspended] = 1 ) AS findings ORDER BY CASE [Severity] WHEN N'CRITICAL' THEN 1 WHEN N'WARNING' THEN 2 WHEN N'INFO' THEN 3 END ,[AGName] ,[ReplicaServer]; |
What I Validated
A few things the agent got right that I might have missed if I’d written this from scratch:
- The
suspend_reason_desccolumn. When data movement is suspended, this tells you why — administrator action, partner shutdown, redo error, etc. The agent included it automatically, which saves a troubleshooting step. - Commit lag estimation. The
last_commit_timedifference gives you a rough lag estimate, though it’s not a precise SLA metric. The agent added a helpful comment noting that this is an approximation, not a guaranteed latency measurement. - Left joins on listener tables. Not every AG has a listener (especially in dev environments or distributed AG configurations), so inner joins would silently hide those AGs.
One thing I added post-generation: a note that this query must run on the primary replica to see full topology. On a secondary, sys.dm_hadr_availability_replica_states only shows the local replica’s state. The agent didn’t mention this, and it’s a common gotcha.
Beyond the Query: Topology Documentation
One powerful follow-up is asking the agent to generate a human-readable topology document from the query output. I pasted a sample result set into the conversation and prompted:
|
1 2 3 4 |
Given this AG topology data, generate a markdown document that describes the AG configuration in plain language. Include a table per AG showing replicas, their roles, sync modes, and any warnings. Format it so I can paste it into our internal wiki. |
The agent produced a clean document with tables and callouts for each misconfiguration. That’s the kind of documentation that usually doesn’t get written because nobody has time — but with the query output and one prompt, you’ve got it.
Try This Yourself
Run the topology query on any instance with Availability Groups. Even if you think your AG configuration is clean, the misconfiguration detection section often surfaces surprises: a secondary that’s been quietly accumulating redo queue, a read-only routing URL that points to a decommissioned server, or a replica someone switched to synchronous commit during a failover test and never switched back.
For deeper AG monitoring — health tracking over time rather than point-in-time snapshots — see the approach discussed in Post 5. The point-in-time diagnostic here is a complement, not a replacement, for continuous monitoring.
Part of the ALTER DBA ADD AGENT series.
