Blocking Chain Triage with AI
You get the alert: “Blocking detected, 47 sessions waiting.” You open SSMS, run sp_who2, and get back a wall of rows that tells you almost nothing useful. Which session is the head blocker? What’s it doing? How long has it been running? Is it safe to kill?
Blocking chain triage is one of those tasks that’s conceptually simple — find the head, understand what it’s doing, decide what to do — but operationally messy when you’re staring at 50 rows of session data under pressure. An AI agent handles the parsing and pattern recognition; you handle the decision.
Collecting the Right Data
The quality of the agent’s analysis depends entirely on what you feed it. sp_who2 is not enough. You need:
sp_WhoIsActive. Adam Mechanic’s (now maintained by Erik Darling) sp_WhoIsActive is the gold standard. It shows blocking chains, wait types, running statements, and elapsed time in a single result set. If you don’t have it installed, install it.
|
1 2 3 4 5 |
EXEC dbo.[sp_WhoIsActive] @get_outer_command = 1 , @get_plans = 1 , @find_block_leaders = 1 , @sort_order = N'[blocked_session_count] DESC'; |
sys.dm_os_waiting_tasks + sys.dm_exec_requests. If you can’t install sp_WhoIsActive (some shops have restrictions on third-party code), you can build a reasonable blocking chain view from DMVs:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 |
SELECT wt.[session_id] AS [waiting_session_id] , wt.[blocking_session_id] , wt.[wait_type] , wt.[wait_duration_ms] , r.[command] , r.[status] , r.[total_elapsed_time] AS [elapsed_ms] , st.[text] AS [sql_text] , r.[database_id] FROM sys.dm_os_waiting_tasks AS wt INNER JOIN sys.dm_exec_requests AS r ON r.[session_id] = wt.[session_id] CROSS APPLY sys.dm_exec_sql_text(r.[sql_handle]) AS st WHERE wt.[blocking_session_id] IS NOT NULL ORDER BY wt.[wait_duration_ms] DESC; |
sp_BlitzWho. Erik Darling’s sp_BlitzWho provides similar data with additional context. Either tool works — the point is to capture the full blocking chain with query text, wait types, and elapsed times.
Feeding a Blocking Chain to the Agent
Here’s a realistic multi-level blocking chain. Session 87 is the head blocker, three sessions are directly blocked by it, and two more are blocked behind those.
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 |
Here is sp_WhoIsActive output from a production SQL Server 2022 instance experiencing a blocking chain. Analyze this and tell me: 1. Who is the head blocker and what is it doing? 2. How long has the head blocker been running? 3. What's the cascade — how many sessions are affected? 4. Is this a runaway query, an open transaction, or something else? 5. What should I do right now to resolve it? session_id | status | blocked_by | wait_type | wait_ms | sql_text (abbreviated) -----------|-----------|------------|------------|----------|------------------------------------------ 87 | sleeping | NULL | NULL | NULL | (last cmd: UPDATE dbo.Accounts SET ...) 142 | suspended | 87 | LCK_M_S | 127433 | SELECT * FROM dbo.Accounts WHERE ... 198 | suspended | 87 | LCK_M_S | 118221 | SELECT a.AccountID, ... FROM dbo.Accounts a 215 | suspended | 87 | LCK_M_IX | 95102 | UPDATE dbo.Transactions SET ... 301 | suspended | 142 | LCK_M_S | 89445 | SELECT ... FROM dbo.Accounts ... 318 | suspended | 198 | LCK_M_IS | 72318 | SELECT TOP 100 ... FROM dbo.Accounts ... Head blocker (87) outer command: BEGIN TRAN UPDATE dbo.Accounts SET ... Head blocker open_tran_count: 1 Head blocker login: CORP\jsmith Head blocker host: DESKTOP-JSMITH7 Head blocker program: Microsoft SQL Server Management Studio - Query Head blocker elapsed time: 00:14:22 |
What the Agent Identifies
The agent processes this quickly and returns a structured analysis:
Head blocker: Session 87. Status is sleeping with open_tran_count = 1 — this is the most dangerous pattern. The session ran an UPDATE, but it’s sleeping, which means the query finished but the transaction was never committed. The BEGIN TRAN in the outer command confirms it: someone opened an explicit transaction in SSMS and walked away.
Cascade impact. Three sessions (142, 198, 215) are directly blocked by session 87. Two more (301, 318) are blocked transitively — they’re waiting on sessions that are themselves waiting on 87. Total: 5 sessions blocked, the longest waiting over 2 minutes.
Lock types tell the story. Sessions 142 and 198 are waiting for shared (S) locks — they’re just trying to read dbo.Accounts. Session 215 is waiting for an intent-exclusive (IX) lock — it’s trying to write to dbo.Transactions, which likely shares a lock resource with the head blocker’s uncommitted update. The head blocker is holding exclusive (X) locks from its uncommitted UPDATE.
Resolution recommendation. The agent suggests:
- Contact the user. The login
CORP\jsmithconnected fromDESKTOP-JSMITH7via SSMS. This is likely a developer or analyst who ran an ad-hoc update with an explicit transaction and forgot to commit. Call them first. - If unreachable, kill session 87. The transaction has been open for 14 minutes with a sleeping session — it’s not going to commit on its own. Killing it will roll back the uncommitted update and release all blocked sessions.
- Prevent recurrence. Suggest setting
SET LOCK_TIMEOUTon the application connections, and consider implementing a monitoring job that alerts on sleeping sessions with open transactions older than a configurable threshold.
What I Did
The agent’s analysis was spot-on. I tried calling the developer first — no answer. After confirming with the application team that no critical batch process was running under that login, I killed the session:
|
1 |
KILL 87; |
All five blocked sessions resumed immediately. The rollback was fast — the UPDATE had only modified a few hundred rows.
For the prevention side, I added an automated check using SQL Server Agent:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 |
/* Alert on sleeping sessions with open transactions > 5 minutes */ IF EXISTS ( SELECT 1 FROM sys.dm_exec_sessions AS s INNER JOIN sys.dm_tran_session_transactions AS t ON t.[session_id] = s.[session_id] WHERE s.[status] = N'sleeping' AND s.[open_transaction_count] > 0 AND s.[last_request_end_time] < DATEADD(MINUTE, -5, SYSDATETIME()) AND s.[is_user_process] = 1 ) BEGIN /* Send alert via Database Mail */ EXEC msdb.dbo.[sp_send_dbmail] @profile_name = N'DBA Alerts' , @recipients = N'dba-team@example.com' , @subject = N'Sleeping session with open transaction detected' , @body = N'Check sys.dm_exec_sessions for sleeping sessions with open transactions.'; END; |
The Pattern That Matters
The real value here isn’t that the agent told me to kill session 87 — I would have figured that out. The value is in the speed of the structured analysis. In 30 seconds, the agent:
- Identified the head blocker from a wall of session data
- Recognized the sleeping-with-open-transaction pattern
- Mapped the full cascade including transitive blocking
- Explained the lock types and what they meant
- Gave me a prioritized action list
During an active blocking event, those 30 seconds matter. Every minute session 87 stays open, more queries pile up behind it.
Try This Yourself
- Install sp_WhoIsActive if you haven’t already — it’s free and open source.
- Next time you see blocking, capture the output with
@find_block_leaders = 1and@get_outer_command = 1. - Paste the full output into your AI agent with the prompt structure above.
- Compare the agent’s analysis speed to your manual triage time — especially on complex chains with 10+ blocked sessions.
- Build the sleeping-transaction monitoring job above and adjust the threshold for your environment.
The agent is fast at reading structured data. But the kill/don’t-kill decision is yours — you need to understand what the transaction was doing and whether rolling it back will cause a bigger problem than the blocking itself.
For the full context on AI-assisted wait stats and blocking analysis, see Post 8: Wait Stats, Deadlocks, and Blocking Chains.
Part of the ALTER DBA ADD AGENT series.
