AI-Generated Availability Group Failover Runbook
Planned AG failovers aren’t technically difficult. ALTER AVAILABILITY GROUP ... FAILOVER is one line of T-SQL. But anyone who’s done them in production knows the real work isn’t the failover command — it’s the 30 minutes of checks before and after. Are all replicas synchronized? Is the redo queue drained? Are applications reconnecting to the listener? Did that third-party monitoring tool lose its mind?
I’ve done enough of these that I have a mental checklist. The problem with mental checklists is that at 6 AM during a patching window, you skip steps. I wanted a scripted runbook that enforces the checklist — and I wanted it built faster than the three hours it would take me to write from scratch.
Here’s the prompt I used:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 |
Write a PowerShell AG failover runbook script using dbatools. The script should accept parameters for the AG name and the target replica. It needs four phases: Phase 1 - Pre-Failover Checks: - Verify all replicas are connected and healthy - Verify all databases are in SYNCHRONIZED state - Check that the redo queue size is under 1 MB on the target replica - Check that the send queue size is under 1 MB - Verify the target replica is in SYNCHRONOUS_COMMIT mode - Verify no active backup or DBCC jobs are running on either replica (check msdb.dbo.sysjobactivity for running jobs matching common backup/DBCC job name patterns) - Display the current primary and all replica roles Phase 2 - Failover Execution: - Prompt for confirmation with a clear summary of what will happen - Perform the failover using Invoke-DbaAgFailover - Wait for the failover to complete Phase 3 - Post-Failover Validation: - Verify the new primary is the expected target replica - Verify all databases are online on the new primary - Test listener connectivity with Test-DbaConnection - Verify all replicas are synchronizing or synchronized - Check that sys.databases shows all AG databases as ONLINE Phase 4 - Rollback Guidance: - If any post-check fails, display step-by-step rollback instructions - Do NOT auto-rollback — just tell the operator what to do Include a -DryRun switch that runs all pre-checks and shows what would happen, without executing the failover. Log every step with timestamps using Write-Verbose. Use splatting for long parameter lists. |
What the Agent Produced
The agent built a well-structured Invoke-AgFailoverRunbook function with the four phases clearly separated. A few things it got right out of the gate:
- Pre-checks that actually block. Each check returns a pass/fail, and the script exits if any pre-check fails. No “warning, continuing anyway” — a hard stop.
- The confirmation prompt showed a formatted summary: current primary, target replica, number of databases, AG name. Clear enough that a sleep-deprived DBA at 6 AM can read it and confirm.
- The
-DryRunmode ran all Phase 1 checks, displayed the planned action, then exited — exactly what I need for pre-validating during change management.
What needed work:
- Job detection was too broad. The agent checked for any running job. I refined it to look for jobs with names matching patterns like
%backup%,%CHECKDB%,%integrity%,%index%— the maintenance jobs that would conflict with a failover. - It didn’t check the AG listener. Pre-failover, I want to verify the listener is resolving to the current primary. Post-failover, I want to verify it resolves to the new primary. This confirms DNS and networking are working, not just the AG metadata.
- Timeout handling was missing. The failover usually completes in seconds, but sometimes the redo queue needs to drain. I asked the agent to add a configurable timeout with a polling loop.
The Iteration
|
1 2 3 4 5 6 7 8 9 10 11 |
Add these improvements: 1. Before failover, resolve the AG listener DNS name and verify it points to the current primary's IP. After failover, poll until the listener resolves to the new primary's IP, with a 60-second timeout. 2. Add a -TimeoutSeconds parameter (default 120) that controls how long the script waits for all databases to reach SYNCHRONIZED state after failover. 3. Narrow the running-job check to jobs whose names match '%backup%', '%checkdb%', '%integrity%', '%index%', or '%maintenance%'. 4. After all post-checks pass, output a structured summary object with before/after state, failover duration, and pass/fail for each check. |
The agent handled all four. The listener DNS check used Resolve-DnsName, which is exactly right.
The Final Runbook
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222 223 224 225 226 227 228 229 230 231 232 233 234 235 236 237 238 239 240 241 242 243 244 245 246 247 248 249 250 251 252 253 254 255 256 257 258 259 260 261 262 263 264 265 266 267 268 269 270 271 272 273 274 |
function Invoke-AgFailoverRunbook { [CmdletBinding()] param( [Parameter(Mandatory)] [string]$AvailabilityGroup, [Parameter(Mandatory)] [string]$TargetReplica, [Parameter(Mandatory)] [string]$ListenerName, [int]$TimeoutSeconds = 120, [switch]$DryRun ) $startTime = Get-Date $results = [System.Collections.Generic.List[PSCustomObject]]::new() function Write-Check { param([string]$Check, [string]$Status, [string]$Detail) $entry = [PSCustomObject]@{ Timestamp = (Get-Date).ToString('HH:mm:ss') Check = $Check Status = $Status Detail = $Detail } $results.Add($entry) $color = if ($Status -eq 'PASS') { 'Green' } else { 'Red' } Write-Host " [$Status] $Check - $Detail" -ForegroundColor $color } /* ── Phase 1: Pre-Failover Checks ── */ Write-Host "`n=== Phase 1: Pre-Failover Checks ===" -ForegroundColor Cyan $agReplicas = Get-DbaAgReplica -SqlInstance $TargetReplica ` -AvailabilityGroup $AvailabilityGroup $currentPrimary = ($agReplicas | Where-Object { $_.Role -eq 'Primary' }).Name if (-not $currentPrimary) { Write-Check -Check 'Primary Identification' -Status 'FAIL' ` -Detail 'Cannot identify current primary replica' return } Write-Check -Check 'Primary Identification' -Status 'PASS' ` -Detail "Current primary: $currentPrimary" if ($currentPrimary -eq $TargetReplica) { Write-Check -Check 'Target Validation' -Status 'FAIL' ` -Detail "$TargetReplica is already the primary" return } /* Check replica health */ $unhealthy = $agReplicas | Where-Object { $_.ConnectionState -ne 'Connected' -or $_.RollupSynchronizationState -ne 'Synchronized' } if ($unhealthy) { $names = ($unhealthy | ForEach-Object { $_.Name }) -join ', ' Write-Check -Check 'Replica Health' -Status 'FAIL' ` -Detail "Unhealthy replicas: $names" return } Write-Check -Check 'Replica Health' -Status 'PASS' ` -Detail 'All replicas connected and synchronized' /* Check target is synchronous commit */ $targetConfig = $agReplicas | Where-Object { $_.Name -eq $TargetReplica } if ($targetConfig.AvailabilityMode -ne 'SynchronousCommit') { Write-Check -Check 'Commit Mode' -Status 'FAIL' ` -Detail "$TargetReplica is in $($targetConfig.AvailabilityMode) mode" return } Write-Check -Check 'Commit Mode' -Status 'PASS' ` -Detail "$TargetReplica is SYNCHRONOUS_COMMIT" /* Check queue sizes on the target */ $dbStates = Get-DbaAgDatabase -SqlInstance $currentPrimary ` -AvailabilityGroup $AvailabilityGroup $highQueue = $dbStates | Where-Object { $_.ReplicaName -eq $TargetReplica } | Where-Object { $_.RedoQueueSize -gt 1024 -or $_.SendQueueSize -gt 1024 /* KB */ } if ($highQueue) { $names = ($highQueue | ForEach-Object { $_.DatabaseName }) -join ', ' Write-Check -Check 'Queue Sizes' -Status 'FAIL' ` -Detail "High queue on: $names" return } Write-Check -Check 'Queue Sizes' -Status 'PASS' ` -Detail 'Redo and send queues under 1 MB' /* Check for running maintenance jobs */ $jobPatterns = @('%backup%', '%checkdb%', '%integrity%', '%index%', '%maintenance%') $runningJobs = foreach ($pattern in $jobPatterns) { $query = @" /* Check for running maintenance jobs */ SELECT j.[name] FROM msdb.dbo.[sysjobactivity] AS ja INNER JOIN msdb.dbo.[sysjobs] AS j ON ja.[job_id] = j.[job_id] WHERE ja.[start_execution_date] IS NOT NULL AND ja.[stop_execution_date] IS NULL AND j.[name] LIKE '$pattern'; "@ Invoke-DbaQuery -SqlInstance $currentPrimary, $TargetReplica ` -Query $query -EnableException } if ($runningJobs) { $jobNames = ($runningJobs | ForEach-Object { $_.name }) -join ', ' Write-Check -Check 'Running Jobs' -Status 'FAIL' ` -Detail "Active maintenance jobs: $jobNames" return } Write-Check -Check 'Running Jobs' -Status 'PASS' ` -Detail 'No conflicting maintenance jobs running' /* Check listener DNS */ try { $listenerIp = (Resolve-DnsName -Name $ListenerName -ErrorAction Stop).IPAddress Write-Check -Check 'Listener DNS' -Status 'PASS' ` -Detail "Listener resolves to $($listenerIp -join ', ')" } catch { Write-Check -Check 'Listener DNS' -Status 'FAIL' ` -Detail "Cannot resolve listener: $ListenerName" return } /* ── DryRun Exit ── */ if ($DryRun) { Write-Host "`n[DryRun] Would fail over AG '$AvailabilityGroup'" ` -ForegroundColor Yellow Write-Host "[DryRun] From: $currentPrimary" -ForegroundColor Yellow Write-Host "[DryRun] To: $TargetReplica" -ForegroundColor Yellow $results | Format-Table -AutoSize return } /* ── Phase 2: Failover Execution ── */ Write-Host "`n=== Phase 2: Failover Execution ===" -ForegroundColor Cyan Write-Host " AG: $AvailabilityGroup" Write-Host " From: $currentPrimary" Write-Host " To: $TargetReplica" Write-Host "" $confirm = Read-Host "Type 'FAILOVER' to proceed (anything else to abort)" if ($confirm -ne 'FAILOVER') { Write-Host 'Failover aborted by operator.' -ForegroundColor Yellow return } $splatFailover = @{ SqlInstance = $TargetReplica AvailabilityGroup = $AvailabilityGroup EnableException = $true } try { $failoverStart = Get-Date Invoke-DbaAgFailover @splatFailover $failoverDuration = (Get-Date) - $failoverStart Write-Check -Check 'Failover Command' -Status 'PASS' ` -Detail "Completed in $($failoverDuration.TotalSeconds.ToString('F1'))s" } catch { Write-Check -Check 'Failover Command' -Status 'FAIL' ` -Detail $_.Exception.Message Write-Host "`n=== ROLLBACK GUIDANCE ===" -ForegroundColor Red Write-Host "1. Check AG state: Get-DbaAgReplica -SqlInstance $currentPrimary" Write-Host "2. If split-brain, force quorum or restart the unintended primary" Write-Host "3. Do NOT attempt automatic rollback — assess manually" return } /* ── Phase 3: Post-Failover Validation ── */ Write-Host "`n=== Phase 3: Post-Failover Validation ===" -ForegroundColor Cyan /* Wait for synchronization with timeout */ $deadline = (Get-Date).AddSeconds($TimeoutSeconds) $synced = $false while ((Get-Date) -lt $deadline) { $postReplicas = Get-DbaAgReplica -SqlInstance $TargetReplica ` -AvailabilityGroup $AvailabilityGroup $newPrimary = ($postReplicas | Where-Object { $_.Role -eq 'Primary' }).Name if ($newPrimary -eq $TargetReplica) { $allSynced = ($postReplicas | Where-Object { $_.Role -eq 'Secondary' -and $_.RollupSynchronizationState -notin 'Synchronized', 'Synchronizing' }).Count -eq 0 if ($allSynced) { $synced = $true; break } } Start-Sleep -Seconds 5 } if ($synced) { Write-Check -Check 'New Primary' -Status 'PASS' ` -Detail "$TargetReplica is now primary" } else { Write-Check -Check 'New Primary' -Status 'FAIL' ` -Detail "Timed out after $TimeoutSeconds seconds" } /* Verify databases online */ $offlineDb = Invoke-DbaQuery -SqlInstance $TargetReplica -Query @" SELECT [name], [state_desc] FROM sys.[databases] WHERE [name] IN ( SELECT d.[name] FROM sys.dm_hadr_database_replica_states AS drs INNER JOIN sys.availability_groups AS ag ON drs.[group_id] = ag.[group_id] INNER JOIN sys.[databases] AS d ON drs.[database_id] = d.[database_id] WHERE ag.[name] = '$AvailabilityGroup' ) AND [state] <> 0; "@ if ($offlineDb) { Write-Check -Check 'Databases Online' -Status 'FAIL' ` -Detail "Offline: $(($offlineDb.name) -join ', ')" } else { Write-Check -Check 'Databases Online' -Status 'PASS' ` -Detail 'All AG databases are ONLINE' } /* Verify listener now resolves correctly */ $connTest = Test-DbaConnection -SqlInstance $ListenerName if ($connTest.ConnectSuccess) { Write-Check -Check 'Listener Connectivity' -Status 'PASS' ` -Detail "Listener is responding on $ListenerName" } else { Write-Check -Check 'Listener Connectivity' -Status 'FAIL' ` -Detail 'Listener connection failed post-failover' } /* ── Phase 4: Rollback Guidance (if needed) ── */ $failedChecks = $results | Where-Object { $_.Status -eq 'FAIL' } if ($failedChecks) { Write-Host "`n=== Phase 4: ROLLBACK GUIDANCE ===" -ForegroundColor Red Write-Host "The following post-failover checks failed:" $failedChecks | Format-Table -AutoSize Write-Host "Manual steps:" Write-Host " 1. Assess AG state: Get-DbaAgReplica -SqlInstance $TargetReplica" Write-Host " 2. If $TargetReplica is primary but unhealthy, fail back:" Write-Host " Invoke-DbaAgFailover -SqlInstance $currentPrimary ``" Write-Host " -AvailabilityGroup $AvailabilityGroup" Write-Host " 3. Verify applications have reconnected to the listener" Write-Host " 4. Do NOT force-failover unless you accept potential data loss" } else { Write-Host "`n=== Failover Complete ===" -ForegroundColor Green } /* Summary output */ [PSCustomObject]@{ AvailabilityGroup = $AvailabilityGroup PreviousPrimary = $currentPrimary NewPrimary = $TargetReplica FailoverDuration = $failoverDuration.ToString('mm\:ss\.ff') TotalDuration = ((Get-Date) - $startTime).ToString('mm\:ss') PreChecksPassed = ($results | Where-Object { $_.Status -eq 'PASS' }).Count PostChecksFailed = ($failedChecks).Count OverallResult = if ($failedChecks) { 'NEEDS ATTENTION' } else { 'SUCCESS' } } } |
What I Validated
I ran this with -DryRun against a non-production AG first. A few things I caught:
- The running-job query needs to cover both replicas. The original only checked the primary. If a
CHECKDBjob is running on the target secondary, failing over to it would be disruptive. TheInvoke-DbaQuery -SqlInstance $currentPrimary, $TargetReplicahandles both. - Listener DNS propagation isn’t instant. After failover,
Resolve-DnsNamemay return the old IP for a few seconds. The polling loop with a timeout handles this gracefully — but set your timeout appropriately for your DNS TTL. - The confirmation prompt is crucial. During a patching window with multiple AGs, it’s easy to pass the wrong target replica. The explicit “type FAILOVER” prompt is intentionally friction — a safety net against mistakes at 5 AM.
This script lives in our shared DBA tools repository. Every planned failover uses it. The -DryRun output is included in our change management tickets as evidence that pre-checks passed before we committed to the failover.
For the fleet health checks that feed into this runbook, see Post 5: Health Checks and Inventory. For more PowerShell automation patterns, see Post 6: PowerShell Automation.
Try This Yourself
Take this runbook and run it with -DryRun against one of your AGs. The pre-checks alone are valuable — they’ll tell you whether your AG is actually ready for a failover right now. Most DBAs find at least one surprise: a replica that’s in ASYNCHRONOUS_COMMIT mode when it should be synchronous, a redo queue that’s larger than expected, or a backup job that’s still running from last night.
Then customize it. Ask the agent to add checks specific to your environment: verify that a particular Windows service is running on the target, check that enough disk space exists for tempdb on the failover target, or add a post-failover step that updates a CMDB. Each iteration takes one prompt and a few minutes of review.
Part of the ALTER DBA ADD AGENT series.
