Migration Planning: Compatibility Checks and Deprecated Features

SQL Server version upgrades are the kind of project that sounds straightforward and never is. You run your assessment tooling — Azure Arc migration assessment, the Database Experimentation Assistant, or even just your own diagnostic scripts — get a report with 200 findings, and then spend weeks figuring out which ones actually matter for your environment. The upgrade itself might take a weekend. The planning takes months.

An AI agent won’t do the upgrade for you. But it can compress the planning phase by doing the tedious scanning, categorizing, and report generation that eats most of that time.

Deprecated Feature Detection

Every SQL Server version deprecates features, and some removes them entirely. The challenge isn’t finding the lists — Microsoft publishes those. The challenge is finding which ones your code uses.

For reference, here’s the compatibility level matrix most DBAs keep in their heads:

The agent scans sys.sql_modules definitions and flags the matches, categorized by severity. It’s not perfect — regex matching on procedure text has the same limitations we discussed in the security post with dynamic SQL scanning — but it catches the vast majority of deprecated usage in static code.

What it can’t catch: deprecated features used in application-side SQL, SQL Agent job steps, SSIS packages, and dynamic SQL built at runtime. For runtime detection, use the SQLServer:Deprecated Features performance counters and the deprecation_announcement / deprecation_final_support Extended Events — these capture actual deprecated feature usage during normal workload execution, which is the only way to find what static code analysis misses.

Also check sys.server_sql_modules for server-level code: logon triggers, endpoints, and other objects that live outside user databases.

Try This Yourself: Pick your oldest database — the one everyone is afraid to touch — and run the deprecated feature scan. You’ll almost certainly find sysprocesses references, old-style RAISERROR calls, and probably a few text columns that should have been converted to varchar(max) a decade ago.

Compatibility Level Assessment

Changing the database compatibility level is where the real risk lives. It’s not just about deprecated features — it affects query optimizer behavior, cardinality estimation, and execution plan selection.

The agent generates a detailed breakdown of optimizer behavior changes by compatibility level. The real value is the testing strategy — it outlines a Query Store-based approach where you capture baseline plans at the old compat level, upgrade, compare, and force known-good plans for any regressions.

Critical sequence: enable Query Store and capture a meaningful baseline before changing the compatibility level. If you change compat level first, you have no before-picture to compare against. This is exactly the kind of step that’s easy to skip under time pressure and painful to realize you missed.

Breaking Change Analysis

Beyond deprecated features and compat level changes, there are outright breaking changes that will cause failures — not just regressions.

The agent categorizes findings by severity, which is the part that takes the most time manually. “Will this actually break, or is it just a warning I can defer?” is the question you ask two hundred times during migration planning. Having that triage done for you — even approximately — saves days.

Migration Runbook Generation

Once you know what needs fixing, you need a runbook. Every migration has the same structure — pre-checks, backup, execute, validate, rollback plan — but every environment has different specifics.

The agent generates a structured runbook you can customize for your environment. It won’t know your specific server names, maintenance windows, or change management process — you fill those in. But the structure, the safety checks, and the order of operations follow well-documented best practices.

AG rolling upgrade — the nuances that matter:

The agent should recommend upgrading secondaries first, then failing over to an upgraded node. But the details are where mistakes happen:

• Upgrade asynchronous DR replicas first, then synchronous secondaries
• Disable automatic failover during the entire operation
• Only fail over to a secondary that is fully synchronized — check synchronization_state before pulling the trigger
• Readable secondary routing may need to be temporarily disabled during the upgrade
• Once the primary is on the newer version, it cannot ship logs to older-version secondaries — this is a one-way door
• Rollback reality: before you fail over to an upgraded replica, rollback is straightforward — just rebuild the upgraded secondary. After failover, the upgraded instance becomes the primary and databases start using the new version’s internal format. At that point, “rolling back” means restore from backup, rebuild the AG, and reseed — not just failing back. Make sure your change management plan accounts for this.

If the agent doesn’t include these caveats in a generated runbook, add them yourself. If it suggests upgrading the primary first, treat that as a red flag.

Cloud Migration Considerations

If your migration target is Azure SQL Database or Managed Instance rather than a new on-premises SQL Server, the compatibility matrix gets more complex.

The agent produces a gap analysis, but this is an area where you need to be precise — vague “it works differently” isn’t helpful.

Some specifics for Azure SQL Managed Instance:
– Cross-database queries generally work on MI (unlike Azure SQL Database, where they don’t)
– Linked servers are supported, but with restrictions on providers and authentication
– SQL Agent exists on MI, but some subsystems and job step types are limited
– CLR assemblies are supported with restrictions (SAFE only by default, EXTERNAL_ACCESS requires configuration)
– Some xp_ procedures don’t exist, and xp_cmdshell behavior differs
– Filestream and FileTables are not supported
– Service Broker works within a single MI, not across instances

A strong caveat: Azure feature support evolves constantly. The agent’s training data has a cutoff date, and Azure SQL adds capabilities frequently. Always verify the agent’s Azure compatibility claims against the current Microsoft documentation. Use the agent’s output as a checklist of things to verify, not as a definitive compatibility matrix.

Don’t Forget the Adjacent Components

Database engine code is only part of the picture. Before any migration, inventory everything that touches the instance:

• SSIS packages — do they reference deprecated OLE DB providers or connection modes?
• SSRS/SSAS — do they need separate upgrade planning?
• Replication and CDC — version compatibility between publisher and subscriber
• Client drivers — ODBC, OLE DB, .NET SqlClient versions and TLS compatibility
• Agent jobs — CmdExec steps, PowerShell steps, SSIS package references
• Linked servers and credentials — provider compatibility on the new version
• Vendor applications — certified version support

Ask the agent to generate an inventory checklist for your specific environment. The more context you give it — server configuration, installed features, job definitions — the more thorough the checklist will be.

Deep Dives

Want to go deeper? These companion posts walk through specific scenarios in detail:

• AI-Assisted Deprecated Feature Scanning — Finding deprecated features
• AI-Assisted Azure SQL Feasibility Assessment — Evaluating Azure migration readiness
• AI-Assisted Post-Migration Validation — Verifying migration success

Next up: AI-Native Monitoring: PerformanceMonitor, PerformanceStudio, and the MCP Revolution — DBA tools built with AI integration from the ground up.

Part of the ALTER DBA ADD AGENT series — Previous: Security Audits
