I Shaved 156 MB Off My Blog by Converting PNGs to WebP

2026-05-18 · by Hannah Vernon · in tools

A factory conveyor belt where oversized PNG cubes pass through a compression machine and emerge as tiny polished WebP gems, monitored by a woman engineer

I just shaved 156 MB off my blog. Not the database, not the theme, not some plugin audit. The images.

The Problem Nobody Talks About

If you use AI to generate featured images for your blog posts, those PNGs are probably massive. I never thought to check mine. Then I did.

139 featured images. All PNG. Average size: 2.7 MB. The largest: 8.3 MB. Total media weight: roughly 168 MB of featured images alone.

Every visitor to any post was downloading 1.5-8 MB just for the hero image before reading a single word. WordPress generates six derivative sizes per upload, so my media library was full of enormous PNG thumbnails that nobody asked for.

AI image generators (Gemini, DALL-E, Midjourney) output PNG by default because it’s lossless. That’s great for archival. It’s terrible for web delivery.

WebP: The Fix

WebP is Google’s image format, and it’s been supported by every major browser since Safari 16 in late 2022. Global browser support is north of 97%. If your visitors are using a browser that can’t render WebP, they have bigger problems than your blog images.

The pitch: lossy WebP at quality 90 produces images visually indistinguishable from the PNG original, at a fraction of the file size.

How much of a fraction? Here’s what I measured on my actual images:

Image Type	PNG Size	WebP Q90	Savings
1536×1024 (typical AI)	1,880 KB	138 KB	91%
1734×907 (wide format)	2,378 KB	196 KB	92%
1424×752 (flat color areas)	8,308 KB	105 KB	99%

That’s not a typo. An 8.3 MB image became 105 KB. AI-generated images compress extraordinarily well in WebP because they have large regions of smooth color gradients – exactly the kind of content WebP’s predictive coding eats for breakfast.

The Non-Obvious Blocker: IIS

I run WordPress on Windows with IIS (yes, really – it works great, and I’ll fight anyone who says otherwise). The first thing I discovered is that WordPress will happily accept a WebP upload via the REST API, report success, generate all the derivative sizes, and then… serve a 404 when you try to load the image.

IIS doesn’t know what a .webp file is unless you tell it. Add this to your web.config inside the <system.webServer> section:

</staticContent>

The remove before add is defensive – it prevents a “duplicate entry” error if the MIME type already exists at the machine level.

If you’re on Apache or Nginx, you probably don’t hit this. If you’re on IIS, this will cost you an hour of debugging before you think to check MIME types.

The Tool: cwebp

Google publishes a standalone WebP encoder called cwebp. No installer, no dependencies – just download the zip, extract, and run.

Download: libwebp 1.5.0 for Windows x64

Basic usage:

1	cwebp.exe -q 90 input.png -o output.webp

Quality 90 is the sweet spot. I tested Q70 through Q95 on several images. Below Q85, you start seeing compression artifacts in gradients. Q90 to Q95 is visually identical, but Q90 is 20-30% smaller.

Automating the Bulk Conversion

I had 139 images to convert, and each one needed six steps:

Download the PNG from WordPress
Convert to WebP with cwebp
Upload the WebP back to WordPress
Back up the post’s HTML content (just in case)
Update the post’s featured_media to point to the new image
Find and replace any inline <img> references in the post body

Here’s the PowerShell script that does it all via the WordPress REST API:

[CmdletBinding()]
param(
    [Parameter(Mandatory)]
    [string]$SiteUrl,

[Parameter(Mandatory)]
    [string]$Username,

[Parameter(Mandatory)]
    [string]$AppPassword,

[string]$CwebpPath = "C:\temp\libwebp\libwebp-1.5.0-windows-x64\bin\cwebp.exe",
    [int]$Quality = 90,
    [string]$WorkDir = "C:\temp\webp-batch",
    [int]$BatchSize = 10,
    [int]$Skip = 0
)

$ErrorActionPreference = 'Stop'
New-Item -Path $WorkDir -ItemType Directory -Force | Out-Null

$cred = [Convert]::ToBase64String(
    [Text.Encoding]::ASCII.GetBytes("${Username}:${AppPassword}")
)
$headers = @{
    Authorization = "Basic $cred"
    "User-Agent"  = "WebP-Converter/1.0"
    Referer       = "$SiteUrl/"
}

# Step 1: Build the queue
Write-Host "Fetching posts..."
$allPosts = @()
$page = 1
do {
    $batch = Invoke-RestMethod `
        "$SiteUrl/wp-json/wp/v2/posts?per_page=100&page=$page&_fields=id,slug,featured_media&status=publish,future,draft" `
        -Headers $headers -TimeoutSec 30
    $allPosts += $batch
    $page++
} while ($batch.Count -eq 100)

$postsWithImages = $allPosts | Where-Object { $_.featured_media -gt 0 }
Write-Host "Posts with featured images: $($postsWithImages.Count)"

# Step 2: Filter to PNG-only featured images
$pngPosts = @()
foreach ($p in $postsWithImages) {
    $media = Invoke-RestMethod `
        "$SiteUrl/wp-json/wp/v2/media/$($p.featured_media)?_fields=id,mime_type,source_url" `
        -Headers $headers -TimeoutSec 15
    if ($media.mime_type -eq 'image/png') {
        $pngPosts += [PSCustomObject]@{
            PostId   = $p.id
            PostSlug = $p.slug
            MediaId  = $media.id
            MediaUrl = $media.source_url
            Basename = [IO.Path]::GetFileNameWithoutExtension(
                $media.source_url.Split('/')[-1]
            )
        }
    }
}

Write-Host "PNG featured images to convert: $($pngPosts.Count)"
$queue = $pngPosts | Select-Object -Skip $Skip -First $BatchSize
$rollback = @()

# Step 3: Convert each image
foreach ($item in $queue) {
    $basename = $item.Basename
    Write-Host "--- Post $($item.PostId) ($basename) ---" -NoNewline

try {
        # Download
        $pngPath = Join-Path $WorkDir "$basename.png"
        Invoke-WebRequest $item.MediaUrl -OutFile $pngPath -TimeoutSec 60
        $pngSize = (Get-Item $pngPath).Length

# Convert
        $webpPath = Join-Path $WorkDir "$basename.webp"
        & $CwebpPath -q $Quality $pngPath -o $webpPath -quiet 2>$null
        $webpSize = (Get-Item $webpPath).Length

# Skip if WebP is not smaller
        if ($webpSize -ge $pngSize) {
            Write-Host " SKIP (WebP not smaller)"
            $rollback += [PSCustomObject]@{
                PostId=$item.PostId; OldMediaId=$item.MediaId
                NewMediaId="SKIPPED"; Status="SKIP"
            }
            continue
        }

# Upload WebP via curl (Invoke-RestMethod doesn't handle binary well)
        $uploadResult = curl.exe -s -X POST `
            "$SiteUrl/wp-json/wp/v2/media" `
            -H "Authorization: Basic $cred" `
            -H "Content-Disposition: attachment; filename=$basename.webp" `
            -H "Content-Type: image/webp" `
            --data-binary "@$webpPath" --max-time 30

$newMedia = $uploadResult | ConvertFrom-Json
        if (-not $newMedia.id) { throw "Upload failed" }

# Back up the post content
        $post = Invoke-RestMethod `
            "$SiteUrl/wp-json/wp/v2/posts/$($item.PostId)?context=edit" `
            -Headers $headers -TimeoutSec 30
        [IO.File]::WriteAllText(
            (Join-Path $WorkDir "backup-post-$($item.PostId).html"),
            $post.content.raw
        )

# Replace inline image references
        $newContent = $post.content.raw
        $escaped = [regex]::Escape($basename)
        $refs = [regex]::Matches(
            $newContent,
            "https://[^`"'\s]*$escaped[^`"'\s]*\.png"
        )
        foreach ($ref in $refs) {
            $oldUrl = $ref.Value
            $year = (Get-Date).Year
            $month = (Get-Date).ToString("MM")
            $newUrl = $oldUrl -replace `
                "/uploads/\d{4}/\d{2}/", `
                "/uploads/$year/$month/"
            $newUrl = $newUrl -replace '\.png$', '.webp'
            $newContent = $newContent.Replace($oldUrl, $newUrl)
        }
        $newContent = $newContent.Replace(
            "wp-image-$($item.MediaId)",
            "wp-image-$($newMedia.id)"
        )

# Update the post
        $null = Invoke-RestMethod `
            "$SiteUrl/wp-json/wp/v2/posts/$($item.PostId)" `
            -Method POST -Headers $headers `
            -Body @{
                featured_media = $newMedia.id
                content = $newContent
            } -TimeoutSec 30

$savings = [math]::Round((1 - $webpSize/$pngSize) * 100, 1)
        Write-Host (" {0}KB->{1}KB ({2}%) | OK" -f `
            [math]::Round($pngSize/1024),
            [math]::Round($webpSize/1024),
            $savings)

$rollback += [PSCustomObject]@{
            PostId=$item.PostId; OldMediaId=$item.MediaId
            NewMediaId=$newMedia.id; Status="OK"
        }
    } catch {
        Write-Host " ERROR: $($_.Exception.Message)"
        $rollback += [PSCustomObject]@{
            PostId=$item.PostId; OldMediaId=$item.MediaId
            NewMediaId="FAILED"; Status="ERROR"
        }
    }
}

# Save rollback data
$rollbackPath = Join-Path $WorkDir `
    "rollback-$(Get-Date -Format 'yyyyMMdd-HHmm').csv"
$rollback | Export-Csv $rollbackPath -NoTypeInformation
Write-Host "`nRollback saved to: $rollbackPath"
$rollback | Format-Table -AutoSize
